Introduction of OKTAVIAN

ABOUT OKTAVIAN

OKTAVIAN建物

Welcome to OKTAVIAN!

 OKTAVIAN was built at Osaka University and has been operated since 1981 as an intense deuterium-tritium (D-T) neutron source at 1.5-ns pulses of 103 D-T neutron/pulse or as the maximum continuous neutron source of 3×1012 D-T neutron/s. OKTAVIAN consists of a high-current deuteron beam accelerator for D-T neutron production. Many fusion neutronics experiments have been carried out for the fundamental study of D-T fusion neutron transport characteristics.

OKTAVIAN Map

施設平面図

OKTAVIAN overview

Exterior of the building

建物外観

Control Room


High-intense neutron irradiation room


Nertron intensity 3×1012 n/sec

3H target


Duoplasmatron ion sources


30 mA, D+ beam

Accelerator


Model:Cockroft-Walton Accelerator
300 kV-80 mA Cockcroft,
Accelerating tube: 1200 mm in length

Pluse line


Beam width: 2×10-9sec,
Variable frequency: 2MHz-1kHz, 20 μA
